fire-resistant door EI30 in wood and steel

Back to list

The door specialists RWD Schlatter and Forster Profile Systems have created a mix in a class of its own: a fire-resistant door made of wood and steel or stainless steel. The warmth of wood and the cool elegance of the steel can be combined in different appearances for demanding safety applications indoors. Combinations with sidelights and fanlights are in different variants possible. Especially for hospitals, residential and care homes, schools, reception areas, offices or conference rooms, this door is the ideal choice. In short: it is suitable wherever aesthetic aspects have a high priority and reliable protection is required.

fire-resistant door in wood and steel

  • overview
  • details
overview
Technical details
Material optionssteel and stainless steel
Dimensions

1 leaf door max. width 1320 × 2640 mm

2 leaf door max. width 2640 × 2640 mm

Performance specifications*

fire-resistant doors EI30

sound insulation Rw ≤ 37 dB

System properties

Concealed hinges (applied door closer on demand)

Panic push-bar

RWD Schlatter standard fittings

Frame construction depth 65 mm

Variants

large selection of colors and materials for door leaf surface

also available with priming film for custom painting

*refer to country-specific approvals

details
System section EI30 in steel
System section EI30 in steel
System section EI30 in stainless steel
System section EI30 in stainless steel
references
fire-rated double leaf sliding door EI30 with screen abutment and escape route function. Used system: forster fuego light Hospital Münsterlingen, Switzerland fire-rated double leaf sliding door EI30 with screen abutment and escape route function. Used system: forster fuego light Hospital Münsterlingen, Switzerland Fire-rated doors EI30 as glazed sliding doors with escape route function or as doors with steel frame and wooden door leaf. System: forster fuego light Hospital Münsterligen, Switzerland fire-rated door EI30 with screen abutments. Used profile system: forster fuego light Hospital Münsterlingen, Switzerland fire-rated doors EI30 with steel frame and wooden door leaf. System: forster fuego light Hospital Münsterlingen, Switzerland Fire-resistant sliding door EI30 in steel with screen abutment. Used system: forster fuego light Hospital Münsterlingen, Switzerland

Hospital Münsterlingen

Different doors for fire protection EI30. Sliding doors partially with escape route function and doors with wooden door leaf in a steel frame and glazed side screens.

Münsterlingen, Schweiz

forster fuego light
